Specification of UPS CT-382B (600VA - LINE INTERACTIVE)
CT-382B with this INVERTER 600VA capacity would work when the AC input voltage is low or even precisely missing/dead.
At the time of the AC input voltage under normal circumstances this UPS will continue to stabilize input voltage AC filter & to always clean so that the supply voltage of the AC power to the load attached always stable teganganya including power supply to charge the battery.
When the AC input voltage is extremely low or missing, the INVERTER will automatically update thetake it over with while delivering supply voltage AC power steady NET mounted load & with time of a very short (a very short transfer time).
TECHNICAL SPECIFICATION:
-Model & Type: CT-382B/LINE INTERACTIVE UPS
-Capacity: 600VA/300W
-AC Input Voltage: 160V ~ 250V
-AC Input Current: 1.0 A (max. Load & Charger)
-AC Input Frequency: 50 Hz ± 3%
-AC Input Protection: 3.15 A (Fuse)
/> -Input Voltage: 12V DC
-Internal Input DC Battery: 1 x 12V/7Ah (SLA Battery)
-DC Input Protection: 30A
-INVERTER Output Waveform: SINEWAVE SYNTHESIZED/STEP WAVE (PWM)
-INVERTER Output Voltage: 220V ± 5%
-INVERTER Output Frequency: 50 Hz ± 1%
-INVERTER Output Efficiency: 80% >
-Type: CONSTANT CHARGING VOLTAGE
-CHARGING Voltage: 8.4 V
-CHARGING Current: 1.5 A (Maximum)
-Transfer Time When AIR CONDITIONING IviUT Files: ≤ 4ms
-Back Up Time: 10 min (Nominal Load)
-Indicator: LED & BUZZER (refer to the condition table)
-Operation Temperature: 0-40 ° C
-Dimension (D x W x H): 95 x 340 x 145 mm
-Weight: 6 kg (net); 7 kg (gross)
Note:
